N300RF

Driven type: Engine driven

Compressor；Jap SD5S14(138cc)

Application:5-12m3 van body

Function:Fresh/Frozen

Send Email Get Price Whatsapp
Features Technical Data Application Related Products Inquiry

Features

  • This is a split system which consists of condenser with one fan and evaporator with blower separately.
  • Condenser is roof top mounted of van body
  • The compressor is directly driven by van’s engine.
  • Adopt High Quality Copper Tube and Aluminium Fin to Get High Cooling, Reliable Performance and Long Life.
  • Suitable van body is about 5-12M3 (3.2meters length).
  • This system exclusively designed for fresh applications on van body.

Technical Data

Model N300RF
 Driven Type Engine Driven
 Installation Rooftop Mounted
 Voltage DC12v / DC24V
 Compressor Jap SD5S14(138cc)
 Controller Digital, In Cab
   Cooling Capacity -18℃ -1560W/5330BTU
   0℃ -4400W/15000BTU
   Volume of Body 7-12m3 (-18℃ )
    Refrigerant HFC-404A,1.2-1.4kg
Condenser Fan No. 2 Fan
Dimension 870*865*189mm
Evaporator Blower No. 2 Blower
Air Flow 2900m3/h
Dimension 857*545*173mm
