NAC18B

Driven Type:Engine Driven

Cooling Capacity:18kW

Compressor:PLM27 compressor

Refrigerant:R134A

Application:6.8-7M bus

Send Email Get Price Whatsapp
Features Technical Data Application Related Products Inquiry

Features

  • Adopt High Quality Copper Tube and Aluminium Fin to Get High Cooling, Reliable Performance and Long Life;
  • Unique condenser core structure design has higher heat exchange rate, which is 25% higher cooling capacity than competitors' products
  • Adopt Hydrophilic Aluminum Fin to Suit High Humidity Environment;
  • Above design make our products good performance in above 60℃mid-east countries and coastal area
  • Imported compressor and alternator, expansion valve for long life and easy maintenance

Technical Data

Model No. NAC18B
Application 7M bus
Cooling Capacity 18KW/61400BTU
Evaporator Air Flow 4800M3/H
QTY of Evaporator Blower 4PCs
QTY of Condenser Fan 2PCs
Compressor PLM27 compressor or VALEO TM31 compressor
Expansion Valve Danfoss brand
Dimension of Rooftop Unit 2820×1630×210MM
Weight for Rooftop Unit 158KG

Application
